CARACTÉRISTIQUES
Cadre
Spark Carbon HMF Mainframe with Alloy 6011 Swingarm
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fourche
FOX 34 Float Rhythm Air Grip 3
3-Modes / Kabolt 15x110mm axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 130mm travel
Amortisseur arrière
FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 120-80-Lockout / T165X45mm
Levier de contrôle
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Dérailleur arrière
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Manettes de dérailleur
Shimano Deore SL-M6100-IR / Rapidfire Plus
Ispec EV clamp
Pédalier
Shimano SLX FC-M7120-1 / Hollowtech 2
55mm CL / 32T
Boitier de pédalier
Shimano BB-MT500 / shell 41x92mm
Chaîne
Shimano Deore CN-M6100
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
Freins
Shimano Deore M6120 4 Piston Disc
Disque de frein
Shimano SM-RT64 CL / F&R 180mm
Cintre
Syncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Pro lock-on grips
Potence
Syncros DC 2.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Tige de selle
Syncros Duncan Dropper Post 2.0
31.6mm / S & M size 125mm / L & XL size 150mm
Selle
Syncros Tofino 2.0 Regular
CRMO rails
Jeu de direction
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Moyeu avant
Formula CL-811 / 15x110mm
Moyeu arrière
Formula CL-148M / 12x148mm / Micro Spline
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools
Rayons
Stainless Black 15G / 1.8mm
Jante
Syncros X-30SE / 32H / 30mm
Tubeless ready
Pneu avant
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Soft
Pneu arrière
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Grip
Poids en Kg (App.)
13.5 (Tubless setup)
Poids en Lbs (App.)
29.76 (Tubless setup)
Poids global
128 kg
Le poids total comprend le vélo, le pilote, l’équipement et les bagages supplémentaires.
